IND-800 INDUSTRIAL CHASSIS

Features

Wall or backpanel mount enclosure

Rugged steel chassis

8-slot PC-AT compatible Passive Backplane

shock mounted to withstand vibration

Supports 386, 486, 586 and Pentium plug-in CPU boards

Field replaceable 200 watt power supply

Removable drive cage for mounting one removable drive and tow hard drives

Individual shock mounts for each drive

Positive air pressure generated by dual push-pull cooling fans

Easily removable air filter

Provisions for two DB-25 and DB-9 connectors

IND-800 Mounting Dimensions

The IND-800 is ideally suited for system integrators and end users who require a rugged Industrial PC designed to be mounted on the backpanel of NEMA enclosures. It is specifically intended for applications requiring a system that can endure the extremes of temperature, humidity, airborne contaminants, shock and vitration found on the factory floor.

The IND-800 and it's 8-slot ISA passive backplane are IBM AT compatible and support all popular operating systems, development tools and industrial/scientific application software packages. This combination provides a foundation for creating solutions to a multitude of factory floor and laboratory problems.

A low profile version, designated IND-800LP , is available for applications with severe space constraints. Although is is only six inches deep, it provides all the features of the standard IND-800 execpt for removable drive mounting and the DB connector cut outs.
